- Perfect choice for projects around the home, small workshop, and auto-repair tasks
- Combination 3-in-1 for ultimate convenience
- Advanced IGBT technology, synergic controlled, very easy, precise and simple operation.
- Featured wave-form control system: perfect wave from of volts and amps during short circuits and Arc burning cycles.
- Automatic input voltage fluctuation controller, over-voltage protection, under voltage protection, over current protection, overload protection
- Automatic temperature control, fan on demand function.
- Generator optimised
- 10A Plug - Ideal for home & workshop power supplies
- 18 months warranty with product registration
Accessories Included:
- ARC Leads
- Earth Leads
- TIG Torch
- Plasma Torch
- Argon Regulator
|
| Dimensions |
220x465x330mm |
| Weight |
18kg |
| Input Power Supply - |
230V AC 10A 50/60Hz |
| Nominal DC Open Circuit Voltage (OCV) |
58V |
| Plasma Output Current |
10A-30A |
| Plasma Duty Cycle |
30A@40%, 20A@100% |
| MMA Current Output |
10A-140A |
| MMA Duty Cycle |
140A@25%, 70A@100% |
| TIG Current Output |
10A-160A |
| TIG Duty Cycle |
160A@50%, 112A@100% |
| Plasma Cut Capacity |
8mm |
| Welding Thickness |
12mm |
| MMA Rod Size |
1.6-3.2mm |
| Insulation Class |
IP21 |
| Power Efficiency |
0.85 |
| Power Factor |
0.93 |
| Standards |
EN60974-1:2012 |
| Warranty |
12 months |
|
